Lead Brick Cave – 550 x 550 mm

Name: Lead Brick Cave - 550 x 550 mm - Nuclear Shields
SKU: LB-C-550-550
Price: 5093.70 USD
Availability: InStock

50 mm Pb | inside dimensions: 550 x 550 mm (WxD)

Pre-configured shielded workspace built from interlocking lead bricks. 50mm lead shielding. Inside dimensions: 550 × 550 mm. Wider opening for larger equipment and two-handed procedures. Optional L-block shield with lead glass viewing window. Standard epoxy painted off-white RAL 9010, other colors available upon request.

SKU: LB-C-550-550

Additional information

Shielding material
Lead
Shielding thickness
50 mm
Outside dimensions
650 x 650 x 338 mm (w x d x h)
Inside dimensions
550 x 550 x 238 mm

Product description

The LB-C-550-550 Lead Brick Cave provides a wider working aperture for procedures involving larger equipment or two-handed manipulation inside the shielded zone. The square 550 × 550 mm interior offers balanced proportions with improved lateral access compared to narrower configurations.

Wider opening for equipment access

The 550mm width accommodates dose calibrators, larger vial shields, and equipment setups that won’t fit through a 450mm opening. This configuration suits workstations where instruments remain inside the cave during procedures, or where operators need room to position hands and tools side by side within the protected area.

Nuclear Shields supplies this cave as a complete pre-configured kit. Every brick is included—base, middle, top, corner, start, and end pieces in the exact quantities needed. The interlocking chevron profiles guide assembly without tools or adhesives, creating radiation-tight joints automatically as you stack.

Consistent 50mm lead protection

All walls deliver 50mm lead shielding using our LB-50 interlocking brick system. The offset joint pattern eliminates straight-line radiation paths between bricks, providing uniform attenuation across the entire wall surface. Effective for Tc-99m, I-131, F-18, and similar gamma-emitting isotopes.

Compare all configurations

Select based on your bench space and procedural requirements:

Configuration	Inside Width	Inside Depth	Best For
LB-C-450-550	450 mm	550 mm	Compact workstations, limited bench space
LB-C-450-650	450 mm	650 mm	Deeper workspace, standard vial handling
LB-C-550-550	550 mm	550 mm	Wider workspace, larger equipment
LB-C-550-650	550 mm	650 mm	Maximum working area, multiple items

Add operator shielding with an L-block

For direct viewing during procedures, mount a tabletop L-block shield behind the cave opening. The lead glass window provides radiation protection equivalent to the surrounding lead while maintaining full visibility. Face and upper body shielding lets you work comfortably inside the cave for extended procedures.

Find compatible L-blocks in our tabletop shield range, or view complete shielded workstation options for integrated solutions.

Modular construction

No permanent assembly means your cave moves with your laboratory. Disassemble for relocation, add courses for increased height, or repurpose bricks for other shielding projects. The investment adapts as your facility evolves. Custom sizes beyond the four standard configurations are available on request.
